SUPPLY OF ALUMINUM
PROFILES, PANELS AND SHEETS
PUNCHED, PRESS-BENT AND ANODIZED
NECE has been supplying anodized flat Sheets with guaranteed alloy for years, but now also supplies Panels, Sheets and press-bent Profiles made from Aluminum sheet.
All of these products can be punched and finished with the Anodizing treatment.
The benefits for the customer are considerable:
- aluminum press-bent profiles in L, U, Z, or C shapes with thicknesses of 1.2, 2, or 3 mm, with a maximum length of 3000 mm, and dimensions achievable to the millimeter
- single order
- single point of contact
- minimum production times
- no logistical risks
- single packaging cost
- measurements or a DXF drawing are sufficient
- aluminum sheet guaranteed by NECE
- color matching between sheets and extrudates managed by NECE
NECE has an in-house Technical Department dedicated to finding the best solution to propose to the customer, supported by technical drawings.
In fact, in its 60 years of activity, NECE has frequently encountered the recurrence of various critical issues, such as:
- commercial extruded profiles only with standard sizes
- sheets with non-guaranteed alloy
- logistical complexity of processes carried out by different suppliers
- color matching between laminates and extrusions
- production emergencies due to failure to meet deadlines by other suppliers
- additional processing (with related unforeseen costs) due to design and production errors/oversights
- multiple packaging costs
CUTTING
Linear External Profiling, without concave parts: rectangular, triangular, trapezoidal, etc.
MAX mm 1500 x 3000.
CUTTING AND PUNCHING
Even of complex shapes.
MAX mm 1250 x 5000.
PRESS BENDING
L-PROFILE
T
B
C
D
MIN mm
1.2
7
10
MIN mm
2
8
16
MIN mm
3
17
17
U-PROFILE
A
B
C
D
MIN mm
20
30
10
5
MAX mm
X
X
X
4000
CORRUGATED PROFILE
A
B
C
D
MIN mm
30
30
30
5
MAX mm
X
X
X
4000
C-PROFILE
A
B
C
D
MIN mm
20
40
80
5
MAX mm
X
X
X
4000
NECE Technical Specifications
- MAXIMUM DEVELOPMENT: for the purpose of conducting a technical review of the customer’s design.
- COLOR TOLERANCE: combination of extruded 6060 alloy and rolled 5005 alloy with a tolerance specified at the time of order.
- CUTTING AND PRESSING TOLERANCE: ± 0.5 mm per side.
